UP TO 20 PARKING SPACES ON THE SITE OF 2

Hydro-Park 1127 & 1123 are the most popular parking stackers. They provide a simple and greatly cost-effective way to create 2 dependent parking spaces above each other, suitable for permanent parking, valet parking, car storage, or other places with attendant. Operation can be easily made by a key switch panel on control arm.- Lifting capacity 2700kg or 2300kg.

  • Car heights on ground up to 2050mm.
  • Platform width up to 2500mm.
  • Lifting height adjustable by limit switch
  • Electric auto lock release enables easier operation.
  • 24v control voltage avoids electric shock
  • Galvanized platform, high-heel friendly
  • Bolts & nuts passing 48hrs Salt Spray Test.
  • Driven by hydraulic cylinder + Koreanlifting chain
  • Proven high end quality with CE Certificate,tested by TUV.
Model Hydro-Park 1127 Hydro-Park 1123
Pump motor power 2.2 Kw 2.2 Kw
Pump ow 2.6 ML/r 2.6 ML/r/td>
Pump working pressure 16-17 MPa 16-17 MPa
Hydraulic cylinder Italian Aston seals Italian Aston Seals
Hydraulic oil L-HV 46# L-HV 46#
Lifting chain LH1266 LH1266
Balance chain LH1066 LH1066
Model Hydro-Park 1127 Hydro-Park 1123
Vehicles parked per unit 2 2
Rated capacity 2700 kg 2300 kg
Available car length 5000 mm 5000 mm
Available car width 1850 mm 1850 mm
Available car height 2050 mm 2050 mm
Drive mode Hydraculic cylinder + Chains Hydraculic cylinder + Chains
Operation Key Swithc Key Swithc
Lifting speed <50s <50s
Descending speed <35s <35s
Power supply 100-480V, 1/3P, 50/60Hz 100-480V, 1/3P, 50/60Hz
Finishing Powder coating with Akzo Nobel Powder Powder coating with Akzo Nobel Powder
